Description：
The ceiling nail is a push-through anchor made from zinc-plated steel. and set in the time-saving push-through installation and then hit with the hammer into the drill hole. The expansion wedge is then driven in flush to the nail head. This causes the ceiling anchor to expand against the hole wall. The ceiling nail is ideal for fixing wire and noxious hangers, air lines, and metal profiles.

Material Specification：

Component	Standard	Mechanical Properties
Anchor body	EN 10263	Carbon steel
Drive pin	EN 10263-4	Carbon steel
Corrosion protection	EN ISO 4042	Zinc plating, Min.5 μm

Product Detail

Ceiling Anchor Nail

Features

Typical Application

Product Selection

Techincial Data

Performance Data

Download

• Simple and fast through-fastening

• The simple active principle allows for cost-efficient hammerset installation

• Impact expansion by hammering in, no setting tool is needed

• Suspensions from concrete ceilings with slit-steel straps, punched band, nonius system hangers or wood battens

• The two hit zones (first nail head, then expansion pin) ensure correct installation - especially in narrow drill holes and also ensure high safety in use.

• Conduits

• Suspended Ceilings

• Wire hangers

• Ventilation systems

• Drywall track

• Electrical fixtures

Part No	Size	Diameter(mm)	Length(mm)	Drill Dia(mm)	Box(pcs)
600206040	M6 × 40	5.8	40	6	100
600206070	M6 × 70	5.8	70	6	100

Size	d(mm)	L(mm)	d0(mm)	h1(mm)	tfix(mm)	hef(mm)
M6 × 40	5.8	40	6	40	5	32
M6 × 70	5.8	70	6	55	35	32

* d = Anchor diameter, L= Total length, d0= Drill hole diameter, h1= Min. Drill hole depth, tfix= Fixture thickness, hef=Effective anchorage depth.

Anchor Diameter (mm)	Embedment (mm)	Concrete C20/C25
Anchor Diameter (mm)	Embedment (mm)	Tension Load(KN)
M6 × 40	19.1	1.2
M6 × 70	19.1	1.2
